Product Description:
Specific Description of Characteristic Dimensions
The filter materials and manufacturing processes incorporate imported glass fiber, stainless steel mesh, wood pulp filter paper, and specialized fiber sintered felt sourced from the United States. These materials are known for their uniformity, high tensile strength, and exceptional capacity to hold contaminants.
Utilizing the advanced SUSTAINMICRON technology, the filters feature an electrostatically optimized double-layer media combined with unique two-component fibers, significantly enhancing filtration performance.
Performance and Precision
The filtration accuracy spans a broad spectrum, ranging from 1 micron up to 100 microns. Certain models, including the 0110 series, achieve even finer filtration levels between 0.2 and 5 microns.
Operating effectively within a wide pressure range of 21 to 210 bar, the SUSTAINMICRON technology also contributes to energy efficiency by reducing the initial pressure drop by approximately 30%.
Durability and Reliability
Designed for durability, the filter elements provide a large flow area while minimizing pressure loss. They possess anti-fatigue bending capabilities, allowing them to endure extreme pulses and dynamic load conditions.
These products undergo rigorous testing and have been certified according to international standards such as ISO 2941, which assesses fracture resistance, and ISO 3724, which evaluates fatigue characteristics.
Compatibility and Environmental Considerations
The filters are compatible with a variety of fluids, including general hydraulic oil, phosphate-based hydraulic oil, and water ethylene glycol mixtures.
Emphasizing sustainability, the latest generation of products avoid the use of bisphenol A in their materials. This approach aims to prolong the operational life of both oil and equipment while reducing the overall carbon footprint.
Applications:
HYDAC filters are widely utilized across nearly all industrial sectors that depend on hydraulic and lubrication systems. Their applications span various fields, ensuring efficient filtration solutions tailored to industry-specific requirements.
In the realm of engineering machinery and vehicles, HYDAC filters play a crucial role in hydraulic power systems. They are commonly used in forklifts, construction machinery, agricultural equipment, and trucks, providing reliable performance under demanding conditions.
The filters also serve heavy industry and manufacturing sectors. They are essential for hydraulic and lubrication filtration in metallurgy processes such as blast furnaces and rolling mills, mining equipment like hydraulic supports, heavy-duty machine tools, and paper manufacturing machinery.
Within the energy and electricity industries, HYDAC filters support hydraulic systems for wind power generation. Additionally, they contribute to lubrication and control systems for steam turbines used in thermal and nuclear power plants, ensuring operational stability and safety.
Chemical and process industries benefit from HYDAC’s expertise as well. Their filters are employed for process filtration and media separation in petrochemical plants, chemical processing facilities, and pharmaceutical production environments, maintaining product quality and system efficiency.
Beyond these areas, HYDAC filters find applications in other industrial sectors including textiles, electronics, water treatment, and the food and beverage industry, where liquid purification and pretreatment are critical.
Overall, HYDAC filters have earned a reputation as a dependable solution for demanding industrial applications. This is attributed to their adherence to strict standard certifications, a broad range of available models, and ongoing investment in innovative technologies like the advanced SUSTAINMICRON filtration system.
| 2600 R 001 BN4HC /-KB |
2600 R 005 ECON2 |
2600 R 010 P /-B1 |
2600 R 025 W/HC |
| 2600 R 001 ECON2 |
2600 R 005 ECON2 /-V |
2600 R 010 P /-KB |
2600 R 025 W/HC /-B1 |
| 2600 R 001 ON |
2600 R 005 ECON2 /-V-B4 |
2600 R 010 P /-W |
2600 R 025 W/HC /-B6 |
| 2600 R 001 ON /-B6 |
2600 R 005 ON /-B1.5 |
2600 R 010 P/HC |
2600 R 025 W/HC /-KB |
| 2600 R 001 ON /-V |
2600 R 005 ON /-B4 |
2600 R 010 P/HC /-B2 |
2600 R 025 W/HC /-V |
| 2600 R 001 ON /-V-KB |
2600 R 005 ON /-SFREE-B6 |
2600 R 010 P/HC /-B6 |
2600 R 025 W/HC /-W |
| 2600 R 003 BN4AM |
2600 R 005 ON /-V-SAK |
2600 R 010 P/HC /-KB |
2600 R 040 AM |
| 2600 R 003 BN4AM /-B6 |
2600 R 005 ON /-V-SFREE-KB |
2600 R 010 P/HC /-V-KB |
2600 R 040 AM /-KB |
| 2600 R 003 BN4AM /-KB |
2600 R 005 ON/PO /-KB |
2600 R 010 P/HC /-W |
2600 R 040 AM /-V |
| 2600 R 003 BN4AM /-V |
2600 R 005 V /-V |
2600 R 010 V |
2600 R 040 AM /-V-KB |
| 2600 R 003 BN4AM /-V-KB |
2600 R 010 BN4AM |
2600 R 010 V /-KB |
2600 R 050 W |
| 2600 R 003 BN4HC |
2600 R 010 BN4AM /-B6 |
2600 R 010 V /-V |
2600 R 050 W /-B0.2 |
| 2600 R 003 BN4HC /-B6 |
2600 R 010 BN4AM /-KB |
2600 R 015 MM |
2600 R 050 W /-KB |
| 2600 R 003 BN4HC /-KB |
2600 R 010 BN4AM /-V |
2600 R 020 BN4HC |
2600 R 050 W /-W |
| 2600 R 003 BN4HC /-SFREE-B6 |
2600 R 010 BN4HC |
2600 R 020 BN4HC /-B1 |
2600 R 050 W/HC |
| 2600 R 003 BN4HC /-V |
2600 R 010 BN4HC /-B4-KE50 |
2600 R 020 BN4HC /-B6 |
2600 R 050 W/HC /-B6 |
| 2600 R 003 BN4HC /-V-KB |
2600 R 010 BN4HC /-B6 |
2600 R 020 BN4HC /-KB |
2600 R 050 W/HC /-KB |
| 2600 R 003 ECON2 |
2600 R 010 BN4HC /-KB |
2600 R 020 BN4HC /-V |
2600 R 050 W/HC /-V |
| 2600 R 003 ON /-B1 |
2600 R 010 BN4HC /-SAK |
2600 R 020 BN4HC /-V-B6 |
2600 R 050 W/HC /-V-B6 |
| 2600 R 003 ON /-B3.5 |
2600 R 010 BN4HC /-V |
2600 R 020 BN4HC /-V-KB |
2600 R 050 W/HC /-V-KB |
| 2600 R 003 ON /-B6-CP |
2600 R 010 BN4HC /-V-B4-KE50 |
2600 R 020 ECON2 |
2600 R 100 W |
| 2600 R 003 ON /-SFREE-KB |
2600 R 010 BN4HC /-V-B6 |
2600 R 020 ON /-B1.5 |
2600 R 100 W /-KB |
| 2600 R 003 ON /-V-B6 |
2600 R 010 BN4HC /-V-KB |
2600 R 020 ON/PO /-KB |
2600 R 100 W /-V |
| 2600 R 003 ON /-V-SFREE-KB |
2600 R 010 BN4HX |
2600 R 020 P |
2600 R 100 W /-W |
| 2600 R 003 V |
2600 R 010 BN4HX /-SFREE-KB |
2600 R 020 P /-KB |
2600 R 100 W /-W-KB |
| 2600 R 003 V /-KB |
2600 R 010 ECON2 |
2600 R 020 P /-W |
2600 R 100 W/HC |
| 2600 R 003 V /-V |
2600 R 010 ECON2 /-V |
2600 R 020 P/HC |
2600 R 100 W/HC /-B0.2 |
| 2600 R 003 V /-W |
2600 R 010 MM |
2600 R 020 P/HC /-B1 |
2600 R 100 W/HC /-B6 |
| 2600 R 005 BN4AM /-KB |
2600 R 010 MM /-SFREE |
2600 R 020 P/HC /-B6 |
2600 R 100 W/HC /-KB |
| 2600 R 005 BN4AM /-V-KB |
2600 R 010 ON /-B1 |
2600 R 020 P/HC /-KB |
2600 R 100 W/HC /-V |
| 2600 R 005 BN4HC |
2600 R 010 ON /-B2 |
2600 R 020 P/HC /-W |
2600 R 200 W |
| 2600 R 005 BN4HC /-B3.5 |
2600 R 010 ON /-SFREE |
2600 R 020 V |
2600 R 200 W /-B1 |
| 2600 R 005 BN4HC /-B6 |
2600 R 010 ON /-SFREE-B6 |
2600 R 020 V /-KB |
2600 R 200 W /-KB |
| 2600 R 005 BN4HC /-KB |
2600 R 010 ON /-SO666 |
2600 R 025 W |
2600 R 200 W/HC |
| 2600 R 005 BN4HC /-SFREE |
2600 R 010 ON /-V-SAK |
2600 R 025 W /-B1 |
2600 R 200 W/HC /-B0.2 |
| 2600 R 005 BN4HC /-SFREE-KB |
2600 R 010 ON/PO |
2600 R 025 W /-B6 |
2600 R 200 W/HC /-B6 |
| 2600 R 005 BN4HC /-V |
2600 R 010 ON/PO /-KB |
2600 R 025 W /-KB |
2600 R 200 W/HC /-KB |
| 2600 R 005 BN4HC /-V-B6 |
2600 R 010 ON/PO /-V-KB |
2600 R 025 W /-V |
2600 R 500 |
| 2600 R 005 BN4HC /-V-KB |
2600 R 010 P |
2600 R 025 W /-W |
Support and Services:
Our Hydraulic Filter Element is designed to provide superior filtration performance, ensuring the longevity and efficiency of your hydraulic system. For technical support, our team of experts is available to assist with installation guidance, maintenance tips, and troubleshooting advice to help you achieve optimal filter performance.
We offer comprehensive services including replacement recommendations, compatibility checks, and custom filtration solutions tailored to your specific hydraulic system requirements. Regular maintenance and timely replacement of the Hydraulic Filter Element are crucial to prevent contamination and system failures.
For best results, always use genuine replacement elements and follow the manufacturer’s guidelines for servicing intervals. Our support team can provide detailed technical datasheets, performance specifications, and application advice to ensure that your hydraulic filtration needs are fully met.
Whether you are operating in industrial, mobile, or marine hydraulic systems, our Hydraulic Filter Element support and services are dedicated to maximizing your equipment’s reliability and uptime.
Packing and Shipping:
The Hydraulic Filter Element is carefully packaged to ensure maximum protection during transportation. Each filter element is individually wrapped in a protective plastic sleeve to prevent contamination and damage. The wrapped elements are then placed in sturdy cardboard boxes with cushioning materials to absorb shocks and vibrations.
For bulk orders, the boxes are securely stacked on pallets and shrink-wrapped to prevent movement. All packages are labeled clearly with product information, handling instructions, and shipping details to facilitate smooth logistics.
We use reliable shipping carriers to deliver the Hydraulic Filter Elements safely and on time to our customers worldwide. Special care is taken to comply with all shipping regulations and to ensure that the products arrive in perfect condition, ready for immediate use.
